Vector Network Analyzer 10 MHz-325 GHz (extended to 700 GHz).
DC to 325 GHz signal sources and power sensors
Spectrum analyzer and phase noise measurement capability up to 220 GHz
92 GS/s Arbitrary Waveform Generator
70 GHz and 110 GHz bandwidth sampling and real-time oscilloscopes
noise sources up to 170 GHz
120 Gb/s BERT
Temperature-controlled probe station
DC-70 GHz 2 K cryogenic probestation with adjustable 0-2.5 T vertical field magnet
Access to nanoscale CMOS and SiGe BiCMOS Technologies
2 K Cryogenic probestation with differential DC-70 GHz arms and vertical field magnet
